TB series barrier terminal block has different pitch and specifications, which can meet with customer demand.
Brand:
OLINKItem no.:
TB15-8.9Payment:
Wire transfer, PayPal, Western Union, AlipayProduct origin:
ChinaColor:
BlackGoods stock:
50000Min order:
1000Shipping port:
Xiamen, NingboLead Time:
15
600v 32 amp barrier terminal block with cover
Specification of tb barrier terminal block
| Product name: | Barrier terminal block | Model: | TB15-8.9 |
| Certification: | CE | Rated voltage: | 600V (UL), 750V (IEC) |
| Rated current: | 25A (UL), 32A (IEC) | Wire range: | 22-10 AWG (4mm²) |
| Withstand voltage: | AC 2500V/1 Min | Temperature range: | -30℃ to +120℃ |
| Torque: | 9.0 Kg.cm | Pitch: | 12.0 mm |
| Poles: | 2*2P-2*12P | Housing: | PBT UL94V-0 |
| Contact: | Steel, tin plated or Brass, tin plated | Screw: | M4, Steel, Nickel plated |
Feature of 32 amp terminal block
Application of barrier strip terminal block
